Sealite POSEIDON-1750 - 1750mm dia. Ocean Buoy

For the latest information on prices and availability please contact us on: (800) 596 7245 or sales@mdnautical.com

The Sealite Poseidon-1750 Buoy is manufactured from UV-stabilized, virgin polyethylene and has been specifically designed to withstand the harsh marine environment, and operate reliably with minimal maintenance.

Ports worldwide are realising the advantages of polyethylene buoys over traditional steel models.

The colour pigment is added to the polyethylene during the moulding process, which means that the buoy never requires painting.

The polyethylene material also inhibits marine growth, so the buoy requires cleaning less often than steel types.

Significant advantages of the polyethylene buoy allow the interval between servicing to be far greater and users continually report major cost savings.

The Poseidon-1750 is constructed from 3 parts ensuring ease of deployment and servicing. The float section incorporates two large lifting and mooring points, interconnected by 316-grade stainless steel tie-bars to provide greater strength. The mid-section may be supplied with a large secondary battery enclosure, whilst the top section is designed to carry the buoy’s primary payload.

The Poseidon-1750 can be economically shipped around the globe, with approximately 4pcs and 9pcs being packed in 20ft and 40ft shipping containers respectively.

The following downloads are availableDownload
Product Specifications [ download 1.2 MB ]
Purchase Specification [ download 14 KB ]
Product brochure Espanõl (Spanish language version) [ download 1.2 MB ]

Features of the Sealite POSEIDON-1750

  • Rotationally-moulded to 16mm wall thickness
  • 316-grade stainless steel battery access door & compartment, and grab rail
  • Made from strong, durable UV-stabilized virgin polyethylene
  • Foam filled with closed-cell polyurethane
  • Non-slip deck
  • Stainless steel mooring bush

Advantages of the Sealite POSEIDON-1750

  • High visibility red, green, white or yellow as per IALA recommendations
  • 3 part product: floatation section, mid section & top section
  • Individual colouration of each section to suit IALA colour/configuration Recommendations
  • Excellent buoyancy & stability, and easy to deploy & service
  • No painting ever
  • Cost effective, environmentally friendly & recyclable
General Characteristics - Buoys
Available Colours Red, Green, White, Yellow as per IALA Recommendations
Focal Plane Height (mm/inches) 2500 / 98 3/8 (standard). 3090 / 121 5/8 (with spacer)
Total Float Volume (L/US gal) 1650 / 436
Nominal Freeboard (mm/inches) 445 / 17 1/2
Reserve Buoyancy (kg/lb) 600 / 1323
Maximum Mooring Load (kg/lb) 600 / 1323
Maximum Draft (mm/inches) 970 / 38 1/4
Minimum Freeboard (mm/inches) 200 / 7 7/8
Safe Working Load, 1 point (kg/lb) 2300 / 5070
Safe Working Load, 2 point (kg/lb) 3250 / 7165
Submergence (kg/cm, lb/inch) 24.5 / 137
Visual Area (m2/ft2 1.75 / 18.8
Physical Characteristics - Buoys
Material Rotationally-moulded UV-stabilized virgin polyethylene. Internal 316-grade stainless steel bracing. 316-grade stainless steel fittings. Slip resistance platform
Wall Thickness (mm/inch) 16 / 5/8 (float section)
Filling Closed-cell polyurethane foam (float section)
Ballast (kg/lb) 150 / 330 internal concrete
Height (mm/inch) 3960 / 156
Width (mm/inch) 1750 / 68 7/8
Mass (kg/lb) 436 / 961
Radar Reflector Echomax
Life Expectancy >20 years
Certifications
Quality Assurance ISO9001:2008
Intellectual Property
Trademarks SEALITE® is a registered trademark of Sealite Pty Ltd
Warranty
Warranty 5 years
