Ballast Water Management: Understanding the regulations and the treatment technologies available, 14th Edition, 2023

This 14th edition has been fully revised to reflect current requirements in the management of ballast water since ratification of the BWM Convention.

To assist ship owners with compliance, it sets out national and international ballast water legislation as well as Port State Control and ship administration requirements.

It includes practical considerations relating to system selection, installation/retrofitting, onboard operation, maintenance, monitoring and reporting.

This publication provides up-to-date guidance on BWM regulations and equipment options and will assist ship owners with transition to full compliance with the BWM Convention.

It looks in detail at the various treatment systems and technologies, significant components and the implications for onboard operation, maintenance and contingency measures.

Since 28th October 2020, only BWMS holding a revised 2016 G8/BWMS Code certificate have been permitted to be installed. The book provides an extensive set of data sheets on systems that have been type approved through the USCG and BWM Convention testing procedures. These summarise the treatment technology, type approval certification and system design limitations, so that ship owners can evaluate different systems and make an informed decision before purchasing.

The Appendices contain an updated list of IMO Guidance Documents for the BWM Convention. They also describe key invasive species and illustrate native and invasive geographic ranges. A set of technical diagrams is also provided showing an example technical layout of a BWMS.

INTRODUCTION

The discharge of untreated ballast water (BW) has been a key factor in the transfer of non-indigenous aquatic species that have subsequently established and become pests in various parts of the world. The economic and environmental damage these invasive species can cause has been well documented and the importance of managing untreated BW on board ships cannot be overstated.

National and international regulations to control the spread of non-indigenous aquatic species through the management of BW by ballast water exchange (BWE) have been in effect in most regions and ports for many years. The International Convention for the Control and Management of Ships' Ballast Water and Sediments (BWM Convention) entered into force on 8th September 2017. As of June 2023, there were 95 contracting States to the BWM Convention, representing approximately 92.41% of the world's merchant shipping tonnage.

The BWM Convention has been fully in effect for four years. Between 8th September 2019 and 8th September 2024, all applicable existing ships will have to comply with the D-2 standard by the ship?s next IOPP renewal date.

The United States is not party to the BWM Convention and its ballast water regulations, affecting ships that only discharge ballast in US waters, have been fully in effect since 1st January 2016. The Vessel Incidental Discharge Act (VIDA) 2018 was enacted in December 2018 with the goal of bringing ballast water legislation in the US under one regulatory umbrella. The revised requirements will not be enforceable until at least December 2026, but it is important to note that the current US ballast water regulations are in force and full effect until that time.

With so many BW systems on the market all claiming to meet the standards of the IMO Convention and USCG discharge rule, it is understandable that there has been an element of confusion for decision makers in the shipping industry. However, since 28th October 2020, only BWMS holding a revised 2016 G8/BWMS Code certificate have been permitted to be installed. The revised 2016 G8/BWMS Code testing regime is more comprehensive and thoroughly tests the BWMS for efficacy before awarding Type Approval. The new Type Approval certificates list the system design limitations (SDLs) of each approved BWMS so that ship owners have more information with which to make an informed decision before purchasing. Biological sampling as part of commissioning testing of the BWMS during the initial survey after installation and before issuance of the IBWMC is now mandatory. This will also provide reassurance of the proper operational capabilities of an installed BWMS.
