Region 2.1: Maine South & Massachusetts Cape Elizabeth to Cape Cod

NV-Chart Region 2.1: Maine South & Massachusetts Cape Elizabeth to Cape Cod

Practical to use and accurate in the information and data published: This is the basic concept with which we have developed the nv-charts and the Harbor & Anchorage Pilot Books.

• this Chart Region is based on NOAA data with a new layout, clear cartography and international chart standards

• depths and heights are charted in feet

• channel markers in red and green

• unique color differences, blue for the 6 ft and 18 ft dephts, and green for exposed tidal areas

• contour lines for 12 ft and 30ft depths

• under water reefs are clearly marked with a light green color and the reef above water in darker green

• variable shoals marked in grey-blue

• lighthouses illustrate their light characteristics for better identification

• seaworthy chart layout - perfect chart flow from one chart to the next

• standardized chart scales - passage charts 1:340,000 – coastal charts 1:100,000 and 1:45,000 and detail charts 1:25,000 or less

• waypoints with latitudes and longitudes for GPS input

• arrow-symbols show buoyage direction

• tide information on each chart
