British Admiralty Nautical Chart 3409 Plans in Iran, Oman and the United Arab Emirates
is corrected up to date. Admiralty standard nautical charts comply with Safety of Life at Sea (SOLAS) regulations and are ideal for professional, commercial and recreational use. Charts within the series consist of a range of scales, useful for passage planning, ocean crossings, coastal navigation and entering port. Mariners should always use the largest scale nautical chart appropriate to their needs. In particularly busy seaways such as the English Channel, Gulf of Suez and the Malacca and Singapore Straits, the standard nautical charts are supplemented by mariners routeing guides which provide advice on route planning in these complex areas.
Chart 3409
Main Chart Details
- Chart Title: Plans in Iran, Oman and the United Arab Emirates
- Publication Date: 23/12/1994
- Latest Edition date: 09/12/2010
- Chart Size: 1019 x 640 (mm)
Chart Panel Details
- Panel Name Plan A - Bandar-e Moqam
- Area Name Iran
- Natural Scale 25000
- North Limit 26 59'.10N
- East Limit 53 28'.92E
- South Limit 26 57'.30N
- West Limit 53 26'.50E
- Panel Name Plan B - Chiru
- Area Name Iran
- Natural Scale 35000
- North Limit 26 43'.49N
- East Limit 53 44'.80E
- South Limit 26 41'.30N
- West Limit 53 43'.00E
- Panel Name Plan C - Bandar-e Charak
- Area Name Iran
- Natural Scale 150000
- North Limit 26 45'.00N
- East Limit 54 25'.09E
- South Limit 26 38'.00N
- West Limit 54 11'.00E
- Panel Name Plan D - Sir Abu Nu'ayr
- Area Name United Arab Emirates
- Natural Scale 50000
- North Limit 25 16'.07N
- East Limit 54 15'.76E
- South Limit 25 11'.30N
- West Limit 54 11'.00E
- Panel Name Plan E - Lavan Oil Terminal
- Area Name Iran - Jazireh-ye Lavan
- Natural Scale 25000
- North Limit 26 48'.80N
- East Limit 53 25'.20E
- South Limit 26 44'.80N
- West Limit 53 18'.10E
- Panel Name Plan F - Khawr al Quway' Anchorage
- Area Name Oman
- Natural Scale 15000
- North Limit 26 23'.80N
- East Limit 56 22'.90E
- South Limit 26 18'.60N
- West Limit 56 19'.60E
- Panel Name Plan G - Qeys Anchorage
- Area Name Iran - Jazireh-ye Qeys
- Natural Scale 50000
- North Limit 26 36'.20N
- East Limit 54 03'.38E
- South Limit 26 30'.60N
- West Limit 53 57'.00E
- Panel Name Plan H - Sirri Oil Terminal
- Area Name Iran - Jazireh-ye Sirri
- Natural Scale 25000
- North Limit 25 55'.00N
- East Limit 54 35'.50E
- South Limit 25 52'.20N
- West Limit 54 31'.90E
- Panel Name Plan I - Bandar-e Lengeh
- Area Name Iran
- Natural Scale 25000
- North Limit 26 33'.60N
- East Limit 54 54'.40E
- South Limit 26 30'.80N
- West Limit 54 51'.90E
